PA 640-GSL Carbon & Glass-Filled SLS Printing
PA 640-GSL Nylon 12
Our SLS Carbon & Glass-Filled Material
When your SLS 3D printed parts need serious structural muscle without acting like an anchor, lightweight PA 640-GSL Nylon 12 delivers the ultimate win-win. By combining high-modulus carbon fibers with weight-slashing hollow glass spheres inside a rugged polyamide 12 powder matrix, this composite yields a phenomenal stiffness-to-weight ratio that practically laughs in the face of gravity. You get the exceptional structural rigidity, low warp, and dimensional stability demanded by high-performance aerospace, drone, and motorsport components, all while shedding critical grams. Ditch the false choice between heavy-duty strength and nimble agility when you can effortlessly print both in a single run.
PA 640-GSL Features
- Dark Gray — High-Detail Surface
- Carbon fiber increases the dimensional stability
- Hollow glass beads add increased durability
- Good Strength-to-Weight Ration Properties
- PA 640-GSL (0.82 g/cm³) is about 12–18% lighter than standard PA 12 (0.93–1.00 g/cm³)
- ~10% Reduction of Material-Per-Build Compared to Similar Nylon 12s
- Developed for the UAV industry
Mechanical Properties
| Imperial | Metric | Test Standard | |
|---|---|---|---|
| Ultimate Tensile Strength XY Orientation Z Orientation |
7,170 psi 4,835 psi |
49 MPa 33 MPa |
ASTM D638 |
| Tensile Modulus XY Orientation Z Orientation |
554,000 psi 282,000 psi |
3,816 MPa 1,945 MPa |
ASTM D638 |
| Flexural Modulus XY Orientation Z Orientation |
731,000 psi 626,000 psi |
5,040 MPa 4,313 MPa |
ASTM D790 |
| Elongation at Break XYZ Orientation |
3% | 3% | ASTM D638 |
Thermal Properties
| Imperial | Metric | Test Standard | |
|---|---|---|---|
| Heat Deflection Temperature | 338°F at 264 psi | 170°C at 1.82 MPa | ASTM D648 |
| Heat Deflection Temperature | 356°F at 66 psi | 180°C at 0.45 MPa | ASTM D648 |
Other Properties
| Imperial | Metric | Test Standard | |
|---|---|---|---|
| Bulk Density | 0.214 oz/in3 | 0.37 g/cm3 | ASTM D1895 |
| Sintered Part Density | 0.474 oz/in3 | 0.82 g/cm3 | ASTM D792 |
| Particle Size (D50) | 0.002 inches | 55 microns | Laser Diffraction |
| Particle Size Range (D510-D90) |
0.001 - 0.004 inches |
35 - 100 microns |
Laser Diffraction |
Choosing Your 3D Printing Champion
Picking the right material shouldn't feel like a chemistry quiz, so let's break down the two heavyweights of SLS printing. If you need parts that bend but refuse to break, meet Nylon 11. Born from castor oil—yes, you get green bragging rights—this eco-friendly powerhouse offers incredible impact resistance, making it your go-to for living hinges and high-pressure environments. On the flip side, Nylon 12 is the reliable industry baseline synthesized from petrochemicals. It trades flexibility for rigidity, delivering rock-solid dimensional stability that makes it perfect for complex housings, rugged enclosures, and economical production runs.
NW Rapid SLS Materials
- STOCK Nylon 12:
- PA 2201 Standard
- PA 615-GS Glass-filled
- NON-STOCK Nylon 12:
- PA 2200 Ultra-white
- PA 603-CF Carbon Fiber-filled
- PA 606-FR Fire Retardant
- PA 620-MF Mineral Fiber-filled
- PA 640-GSL Hollow Glass & Carbon Fiber-filled
- Alumide® Metallic Aluminum-filled
- NON-STOCK Nylon 11:
- PA 840-GSL Hollow Glass & Carbon Fiber-filled
- PA 850 Black
- SLS Materials Data Sheet
- SLS Basic Printing Guide
